QUE HÀN ESAB OK AlSi12

Mã sản phẩm: AlSi12-1

Giá gốc 0₫

Covered electrode suitable for welding of aluminium castings of AlSi-, AlSiMg- and AlSiCu-types. Also possible to use as filler material in gas welding.

PHI

Số lượng

Typical Weld Metal Analysis %

SiAlFe
12.4 %87.4 %0.2 %

Deposition Data

DiameterCurrentDeposition RateFusion time per electrode at 90% I maxkg weld metal/kg electrodesNumber of electrodes/kg weld metalVoltage
2.4 x 350 mm50-90 A0.54 kg/h23 sec0.42 kg29423 V
3.2 x 350 mm70-120 A-----

Classifications:EN ISO 18273, AlSi12

Alloy Type:IMPERIAL_Aluminium-silicon alloy, AlSi12
Coating Type:Cloride and Fluoride Salt
Welding Current:DC+
