ĐẦU CẤP DÂY HÀN ESAB Origo Feed 3004/4804, MA23/MA24

Mã sản phẩm: Feed3004MA23

Giá gốc 0₫

The sturdy design of the ESAB Origo™ Feed 3004 and 4804, with their galvanised metal casing, makes these units ideal for use in tough environments. Suitable for Mig 3001i/4001i/4004i/5004i/4002c/5002c and 6502c. Electronically controlled feeding gives an accurate and stable arc and the 4-wheel feeder mechanism with grooves in both the feed roll and pressure roll give a stable feed with low wear on the wire, all of which helps to avoid operational disturbances.

MODEL

Số lượng

Arc Power Specifications

ModelOrigo Feed 3004 / 4804
Conditional StatementSupply Voltage
Input Frequency50/60 Hz
Input VAC42 VAC

Dimensions

Origo Feed 3004 / 4804

Height420 mm
Length690 mm
Width275 mm

Input Voltage

ModelOrigo Feed 3004 / 4804
Frequency50/60 Hz
Voltage42 V

Weight

Origo Feed 3004

Weight15 kg

Origo Feed 4804

Weight19 kg

Welding Output

Model
Origo Feed 3004 / 4804

Wire Feeder Specifications

Conditional QualificationOrigo Feed 3004
Max Spool Diameter300 mm
Wire Feed Speed0.8 - 25.0 m/min
Wire Spool Capacity18 kg
MetalWire Diameter
unall. solid0.6 - 1.6 mm
Stainless Steel0.6 - 1.6 mm
unall. solid0.6 - 2.4 mm
Stainless Steel0.6 - 2.4 mm
Cored Wire0.8 - 1.6 mm
Cored Wire0.8 - 2.4 mm
Aluminum1.0 - 1.6 mm
Aluminum1.0 - 2.4 mm
