Mã sản phẩm: E316L-16-2.5

Giá gốc 0₫

Extra low carbon stainless steel electrode for welding steels of the 18Cr12Ni2.8Mo-type. Also suitable for welding stabilized steels of similar composition except when full creep resistance of the base material is to be matched.


Số lượng

Typical Tensile Properties

AWS As welded
ElongationTensile StrengthYield Strength
42 %590 MPa485 MPa

Typical Charpy V-Notch Properties

AWS As welded
Impact ValueTesting Temperature
60 J20 °C
42 J-60 °C

Deposition Data

DiameterCurrentDeposition RateFusion time per electrode at 90% I maxkg weld metal/kg electrodesNumber of electrodes/kg weld metalVoltage
2.5 x 300 mm45-90 A0.9 kg/h45 sec0.55 kg9629 V
4.0 x 350 mm70-190 A2.0 kg/h57 sec0.56 kg3432 V
3.2 x 350 mm60-125 A1.4 kg/h57 sec0.55 kg5230 V

Classifications:SFA/AWS A5.4, E316L-16, JIS Z 3221, D316L-16

Alloy Type:CrNi
Coating Type:Acid-Rutile
Ferrite Content:FN 3-10
Welding Current:AC, DC+
