QUE HÀN ESAB OK 53.04

Mã sản phẩm: E7016-2.5

Giá gốc 0₫

OK 53.04 is an LMA electrode for welding in all positions, excellent on AC in the vertical position. It has very good running characteristics, gives a low amount of spatter loss and a thin slag, which is easy to remove. The electrode is also characterized by good arc stability at low amperage. For root runs in single V joints welding on DC- is recommended because of the cooler weld pool.

PHI

Số lượng

Typical Tensile Properties

ISO As welded
ElongationTensile StrengthYield Strength
27 %590 MPa500 MPa
AWS As welded
ElongationTensile StrengthYield Strength
---

Typical Charpy V-Notch Properties

ISO As welded
Impact ValueTesting Temperature
110 J-40 °C
AWS As welded
Impact ValueTesting Temperature
--30 °C

Deposition Data

DiameterCurrentDeposition RateFusion time per electrode at 90% I maxkg weld metal/kg electrodesNumber of electrodes/kg weld metalVoltage
2.5 x 350 mm70-110 A0.9 kg/h50 sec0.56 kg81.023 V
4.0 x 350 mm120-190 A1.7 kg/h66 sec0.61 kg3323 V
5.0 x 400 mm150-240 A-----
3.2 x 350 mm90-140 A1.2 kg/h62 sec0.60 kg48.023 V

Approvals:ABS, 3YH5, BKI, 3 Y H15, DNV, 3YH10, GL, 3YH10, LR, 3Y H15
Classifications:SFA/AWS A5.1, E7016, EN ISO 2560-A, E 42 4B 12 H5

Approvals are based on factory location. Please contact ESAB for more information.

Alloy Type:Carbon Manganese
Coating Type:IMPERIAL_Basic covering
Diffusible Hydrogen:< 5.0 ml/100g
Welding Current:AC, DC+(-)
