QUE HÀN ESAB OK 63.30

Mã sản phẩm: E316L-17-2.0

Giá gốc 0₫

Extra low carbon stainless steel electrode for welding steels of the 18Cr 12Ni 2.8Mo-type. Also suitable for welding of stabilized stainless steels of similar composition when the working temperature is maximum 350°C.

PHI

Số lượng

Typical Tensile Properties

ISO As welded
ElongationTensile StrengthYield Strength
40 %570 MPa460 MPa
AWS As welded
ElongationTensile StrengthYield Strength
---

Typical Charpy V-Notch Properties

ISO As welded
Impact ValueTesting Temperature
60 J20 °C
55 J-20 °C
43 J-60 °C

Typical Weld Metal Analysis %

MnMoCSiFerrite FNNiNCr
0.6 %2.6 %0.02 %0.8 %6 %11.0 %0.10 %18.1 %

Deposition Data

DiameterCurrentDeposition RateFusion time per electrode at 90% I maxkg weld metal/kg electrodesNumber of electrodes/kg weld metalVoltage
2.5 x 300 mm45-90 A0.9 kg/h45 sec0.55 kg9629 V
4.0 x 350 mm70-190 A2.0 kg/h57 sec0.56 kg3432 V
1.6 x 300 mm30-45 A0.4 kg/h37 sec0.56 kg25029 V
3.2 x 350 mm60-125 A1.4 kg/h57 sec0.55 kg5230 V
5.0 x 350 mm100-280 A3.0 kg/h63 sec0.56 kg2132 V
2.0 x 300 mm45-65 A0.6 kg/h39 sec0.60 kg14729 V

Approvals:ABS, SFA/AWS A5:4, E316L-17, BV, 316L, CE, EN 13479, CWB, CSA W48: E316L-17, DB, 30.039.06, DNV-GL, VL 316 L, LR, 316L, NAKS/HAKC, 2.5-4.0 mm, Seproz, UNA 272580, VdTÜV, 00262
Classifications:EN ISO 3581-A, E 19 12 3 L R 1 2, SFA/AWS A5.4, E316L-17, CSA W48, E316L-17, Werkstoffnummer, 1.4430

Approvals are based on factory location. Please contact ESAB for more information.

Alloy Type:Austenitic CrNiMo
Ferrite Content:FN 3-10
Welding Current:DC+, AC
