QUE HÀN ESAB OK 67.45

Mã sản phẩm: E307-15-2.5

Giá gốc 0₫

Austenitic stainless-steel electrode producing a weld metal with less than 5% ferrite. The tough weld metal has excellent crack resistance, even when welding steels with very poor weldability. Suitable for joining 12-14% manganese steel to itself or other steels. Also suitable for buffer layers before hardfacing.

PHI

Số lượng

Typical Tensile Properties

ISO As welded
ElongationTensile StrengthYield Strength
35 %605 MPa470 MPa
AWS As welded
ElongationTensile StrengthYield Strength
---

Typical Charpy V-Notch Properties

ISO As welded
Impact ValueTesting Temperature
85 J20 °C
50 J-60 °C

Typical Weld Metal Analysis %

MnCSiFerrite FNNiNCr
6.3 %0.09 %0.3 %2 %9.1 %0.06 %18.8 %

Deposition Data

DiameterCurrentDeposition RateFusion time per electrode at 90% I maxkg weld metal/kg electrodesNumber of electrodes/kg weld metalVoltage
2.5 x 300 mm50-80 A0.7 kg/h50 sec0.58 kg10223 V
4.0 x 350 mm80-140 A1.5 kg/h73 sec0.60 kg3324 V
3.2 x 350 mm70-100 A1.1 kg/h71 sec0.60 kg5124 V
5.0 x 350 mm150-200 A2.2 kg/h80 sec0.60 kg2225 V

Approvals:ABS, Stainless, CE, EN 13479, Seproz, UNA 272580, VdTÜV, 01580
Classifications:EN ISO 3581-A, E 18 8 Mn B 2 2, SFA/AWS A5.4, (E307-15)

Approvals are based on factory location. Please contact ESAB for more information.

Alloy Type:IMPERIAL_Stainless austenitic CrNiMn
Coating Type:Lime Basic
Ferrite Content:FN <5
Welding Current:DC+
