QUE HÀN ESAB OK 94.35

Mã sản phẩm: ECuNi-2.5

Giá gốc 0₫

Copper-nickel electrode used for chemical process equipment, desalination plants and offshore applications. It is suitable for the joining and cladding of matching and dissimilar alloys

PHI

Số lượng


Typical Tensile Properties

AWS As welded
ElongationTensile Strength
30 %400 MPa

Typical Weld Metal Analysis %

MnCuNiFe
1.6 %67 %30 %0.6 %

Deposition Data

DiameterCurrentDeposition RateFusion time per electrode at 90% I maxkg weld metal/kg electrodesNumber of electrodes/kg weld metalVoltage
2.5 x 300 mm55-70 A3.9 kg/h49 sec0.64 kg9322 V
3.2 x 350 mm70-120 A4.4 kg/h50 sec0.66 kg4823 V

Classifications:SFA/AWS A5.6, ECuNi, EN ISO 17777, E Cu 7158 (CuNi30Mn2FeTi)

Alloy Type:Copper Nickel
Coating Type:Basic
Welding Current:DC+
