QUE HÀN ESAB OK AlMn1

Mã sản phẩm: AlMn1-1

Giá gốc 0₫

Covered electrode suitable for welding of Mn-alloyed aluminium and aluminium alloys containing up to 3 % Mg, e.g. EN AW-3103, 3207, 3003, 5005.

PHI

Số lượng

Typical Weld Metal Analysis %

MnSiAlFe
1.3 %0.1 %98.1 %0.3 %

Deposition Data

DiameterCurrentDeposition RateFusion time per electrode at 90% I maxkg weld metal/kg electrodesNumber of electrodes/kg weld metalVoltage
2.4 x 350 mm50-90 A0.51 kg/h24 sec0.41 kg29425 V
3.2 x 350 mm70-120 A1.74 kg/h23 sec0.89 kg8821 V


Classifications:EN ISO 18273, AlMn1


Alloy Type:IMPERIAL_Aluminium alloy AlMn1
Coating Type:Cloride and Fluoride Salt
Welding Current:DC+
