QUE HÀN ESAB OK AlSi5

Mã sản phẩm: AlSi5-2.4

Giá gốc 0₫

Covered electrode suitable for welding of AlMgSi-alloys e.g. EN AW 6060/6063, 6005, 6201 etc. Also suitable for welding of AlSi5Cu- and AlSi7Mg-castings.

PHI

Số lượng

Typical Weld Metal Analysis %

SiAlFe
4.9 %94.9 %0.2 %

Deposition Data

DiameterCurrentDeposition RateFusion time per electrode at 90% I maxkg weld metal/kg electrodesNumber of electrodes/kg weld metalVoltage
2.4 x 350 mm50-90 A0.45 kg/h24 sec0.37 kg33325 V
3.2 x 350 mm70-120 A0.80 kg/h27 sec0.47 kg16623 V

Classifications:EN ISO 18273, AlSi5

Alloy Type:IMPERIAL_Aluminium-silicon alloy, AlSi5
Coating Type:Cloride and Fluoride Salt
Welding Current:DC+
